Technical specifications
| Model | RY-850 | RY-950 | RY-1050 |
| Printing Color | 1-6 Color | 1-6 Color | 1-6 Color |
| Printing Speed | Max.60/min | Max.60/min | Max.60/min |
| Max.Paper Reel Width | 889mm | 950mm | 1050mm |
| Max.Printing Width | 850mm | 930mm | 1020mm |
| Max.Unwinding/Rewinding Diameter | ø1400mm | ø1400mm | ø1400mm |
| Printing Girth | 180-420mm | 180-420mm | 180-420mm |
| Precision Of Chromotography | ±0.15mm | ±0.15mm | ±0.15mm |
| Plate Thickness | 1.7mm | 1.7mm | 1.7mm |
| Paste Plate Tape Thickness | 0.38mm | 0.38mm | 0.38mm |
| Suitable Material Thickness | 150g-420g gsm paper or other | ||
| Main Motor Power | 7.5KW | 7.5KW | 7.5KW |
| Total Power | 25KW | 30KW | 30KW |
| Power Source | 380V 3-phases, 50Hz | 380V 3-phases, 50Hz | 380V 3-phases, 50Hz |
| Dimensions(L*W*H) | 3500*1850*2200mm | 3500*1950*2200mm | |
| Machine Weight | About 3800KG | About 5000KG | About 5500KG |
